TD009 Mirror touch sensor switch ON/OFF + dimming + memory function

Product image 1
1 / 4

TD009 Mirror touch sensor switch ON/OFF + dimming + memory function

Voltage 12~24V DC
Output Current 4A Max
Color Black
Load around 48W for 12V, 96W for 24V
Mirror Thickness <5mm
Usage Single Color
Dimensions 28.5 x 26.4 x 8.5mm(1.1 x 1.03 x 0.3in)
Certification



Feature:

  • Mirror touch switch ON/OFF + dimming + memory function
  • Originally "off" when the power is connected.
  • Quick touch (time is less than 550ms) can turn ON/OFF the light. One touch to turn on, touch again to turn off. The lamp is 90% bright when it is on.
  • Hold on touching (time is above 550ms) can adjust the brightness endlessly. It will reduce the brightness endlessly to the minimum in 3 seconds holding on when the light is on. it will increase the brightness endlessly to 100% in 3 seconds holding on when the light is off.
  • Quick touch and hold on touching can be chosen anytime without any collision.
  • This sensor will memorize the status of the dimming in DC 12V-24V.
          $6.39

          Original: $21.29

          -70%
          TD009 Mirror touch sensor switch ON/OFF + dimming + memory function—

          $21.29

          $6.39

          Product Information

          Shipping & Returns

          Description

          Voltage 12~24V DC
          Output Current 4A Max
          Color Black
          Load around 48W for 12V, 96W for 24V
          Mirror Thickness <5mm
          Usage Single Color
          Dimensions 28.5 x 26.4 x 8.5mm(1.1 x 1.03 x 0.3in)
          Certification



          Feature:

          • Mirror touch switch ON/OFF + dimming + memory function
          • Originally "off" when the power is connected.
          • Quick touch (time is less than 550ms) can turn ON/OFF the light. One touch to turn on, touch again to turn off. The lamp is 90% bright when it is on.
          • Hold on touching (time is above 550ms) can adjust the brightness endlessly. It will reduce the brightness endlessly to the minimum in 3 seconds holding on when the light is on. it will increase the brightness endlessly to 100% in 3 seconds holding on when the light is off.
          • Quick touch and hold on touching can be chosen anytime without any collision.
          • This sensor will memorize the status of the dimming in DC 12V-24V.
