5in1 Dimming Triac/Phase/MLV/ELV/0-10V/Potentiometer/10V PWM LED Driver, 12V 60W

Product image 1
1 / 5

5in1 Dimming Triac/Phase/MLV/ELV/0-10V/Potentiometer/10V PWM LED Driver, 12V 60W

Model VBD-012-060C2DM5i1
Input Voltage 100-277V AC
Input Current 0.9A
Frequency 50-60 Hz
Power Factor >0.95
Output Voltage 12V DC
Output regulated Current 5A
Output Power 60W max
Dimmable Yes (Triac/Phase/MLV/ELV/0-10V/Potentiometer/10V PWM)
IP Rating IP67 (Dry, Damp and Wet Locations)
Dimensions  189mm x 94.57mm x 40.80mm (7.45in x 3.75in x 1.6 in)
Class Certification Class 2
Certifications:
Applicable for dry, damp, and wet locations
Compatible with Forward-Phase, Magnetic low Voltage & Triac dimmers



Features:

  • Class 2 LED driver supporting Triac/Phase/MLV/ELV/0-10V/Potentiometer/10V PWM dimming methods
  • Input voltage range: 100-277V AC, input current: 0.9A, frequency range: 50-60 Hz
  • Power factor greater than 0.95 for efficient power usage
  • Output voltage: 12V DC, regulated output current: 5A, maximum output power: 60W
  • Dimmable driver suitable for use in dry, damp, and wet locations with IP67 rating
  • Dimensions: 189mm x 94.57mm x 40.80mm (7.45in x 3.75in x 1.6 in)
  • Certified by UL and FCC for safety and compliance.
$24.89

Original: $82.97

-70%
5in1 Dimming Triac/Phase/MLV/ELV/0-10V/Potentiometer/10V PWM LED Driver, 12V 60W—

$82.97

$24.89

Product Information

Shipping & Returns

Description

Model VBD-012-060C2DM5i1
Input Voltage 100-277V AC
Input Current 0.9A
Frequency 50-60 Hz
Power Factor >0.95
Output Voltage 12V DC
Output regulated Current 5A
Output Power 60W max
Dimmable Yes (Triac/Phase/MLV/ELV/0-10V/Potentiometer/10V PWM)
IP Rating IP67 (Dry, Damp and Wet Locations)
Dimensions  189mm x 94.57mm x 40.80mm (7.45in x 3.75in x 1.6 in)
Class Certification Class 2
Certifications:
Applicable for dry, damp, and wet locations
Compatible with Forward-Phase, Magnetic low Voltage & Triac dimmers



Features:

  • Class 2 LED driver supporting Triac/Phase/MLV/ELV/0-10V/Potentiometer/10V PWM dimming methods
  • Input voltage range: 100-277V AC, input current: 0.9A, frequency range: 50-60 Hz
  • Power factor greater than 0.95 for efficient power usage
  • Output voltage: 12V DC, regulated output current: 5A, maximum output power: 60W
  • Dimmable driver suitable for use in dry, damp, and wet locations with IP67 rating
  • Dimensions: 189mm x 94.57mm x 40.80mm (7.45in x 3.75in x 1.6 in)
  • Certified by UL and FCC for safety and compliance.
