Model	EVT-V012-24-T1
Input Voltage	120 – 277V AC
Input Current	0.14A
Frequency	50/60Hz
Power Factor	0.9
Output Voltage	24V DC
Output regulated Current	500mA
Output Power	12W max
Dimmable:	Yes (0-10V/Triac/ELV Dimming)
Class Certification	Class P . Class 2
IP Rating	IP20 (Dry or Damp Locations)
Dimensions	440 x 86 x 59.4mm (17.31 x 3.38 x 2.34 in)
Certifications

Features:

• It operates with an input voltage range of 120-277V AC and an input current of 0.14A, with a frequency range of 50/60Hz.
• The LED driver has a power factor of 0.9, indicating high energy efficiency.
• Provides a regulated output voltage of 24V DC with a maximum output power of 12W and an output regulated current of 500mA, suitable for powering high-power LED lights.
• Features 0-10V/Triac/ELV dimming capability for greater flexibility in controlling the brightness of LED lights.

• Designed for Dry or Damp Locations, providing resistance to moisture, dust.

• Certified with Class P and Class 2 certification, indicating compliance with safety standards for use in hazardous locations.
